Model |
DCT1205 |
DCT1210 |
DCT1215 |
DCT1220 |
DCT1230 |
DCT1240 |
DCT4820 |
DCT4830 |
DCT4840 |
|
Battery Voltage |
12V /24V Auto |
12V /24V Auto |
48V |
||||||
|
Charge Current |
5A |
10A |
15A |
20A |
30A |
40A |
20A |
30A |
40A |
|
Discharge Current |
5A |
10A |
15A |
20A |
30A |
40A |
20A |
30A |
40A |
|
Max Solar Input Power |
60/120W |
120/240W |
180/360W |
240/480W |
360/720W |
480/960W |
960W |
1440W |
1920W |
|
Max Solar Voltage |
< 50V |
< 50V |
< 100V |
||||||
|
Float Charge |
13.8/27.6V |
13.8 / 27.6V |
55.2V |
||||||
|
Load Disconnect |
11.2/22.4V |
11.2/ 22.4V |
44.8V |
||||||
|
Load Reconnect |
12.6/ 25.2V |
12.6 / 25.2V |
50.4V |
||||||
|
Self-Consumption |
< 15mA |
||||||||
|
Overload Protection |
Shut down after 60s in case of 130% load; |
||||||||
|
Charging Mode |
PWM (Pulse Width Modulation) |
||||||||
|
Opertating Temperature |
-35°C to +60°C (full load) |
||||||||
|
Protection Class |
IP20 |
||||||||
|
Weight |
0.21kg |
0.21kg |
0.21kg |
0.21kg |
0.263 |
0.263 |
0.266 |
0.27 |
0.27 |
|
Dimension |
139*100*45 mm |
143*90*35mm |
|||||||
|
Safety Standard |
ICE62109-1 |
ICE62109-1 |
|||||||
