Features:
1.High efficiency MPPT control algorithm, MPPT efficiency ≥99.5%,
whole Machine conversion efficiency upto 98%;
2.Charge mode: three stages (fast charge, constant charge, floating charge),
improve boost voltage charge(activate the battery performance), it prolongs
service life of the batteries;
3.Discharge mode: ON/OFF mode, PV voltage control mode, Dual Time control
mode, PV&Time control mode;
4.Customers can choose battery types: (Flooded, Sealed lead acid, Gel
battery) charging, Other types of the batteries can also be defined;
5.Most information could be provide by LCD like: System type, PV input voltage,
PV input current, Day/Month/Total generated energy, battery type, battery
voltage, charging current, charging power, Load current, Load power and so on;
6.RS485 communication, we can offer communication protocol also,
it’s convenient for user’s integration management.
7. CE, RoHS, FCC certifications approved. We can help clients to approve
other certifications.
|
DI-MPPT-12V/24V/36V/48V-series |
20A |
30A |
40A |
|
|
Charge Mode |
MPPT(Maximum Power Point Tracking) |
|||
|
MPPT efficiency |
≥99.5% |
|||
|
System Type |
DC12V/24V/36V/48V |
Automatic recognition |
||
|
Input Characteristic |
||||
|
PV Max. Input voltage (VOC) |
12V/24V/36V/48V |
DC130V |
||
|
system |
||||
|
Start charging voltage point |
12V/24V/36V/48V |
Higher than battery voltage 3V |
||
|
system |
||||
|
Low input voltage protection point |
12V/24V/36V/48V |
Higher than current battery voltage 1V |
||
|
system |
||||
|
Over voltage |
12V/24V/36V/48V system |
DC130V |
||
|
protection point |
||||
|
Rated PV input power |
12V system |
260W |
390W |
520W |
|
24V system |
520W |
780W |
1040W |
|
|
36V system |
780W |
1170W |
1560W |
|
|
48V system |
1040W |
1560W |
2080W |
|
|
Charge Characteristic |
||||
|
Charge mode |
MPPT(Maximum Power Point Tracking) |
|||
|
Charge method |
3-Stage: constant current(fast charging), constant voltage, floating charge |
|||
|
Selectable Battery Types |
Flooded, Sealed lead acid, Gel battery |
|||
|
(Other types of the batteries also can be defined) |
||||
|
Rated charge current |
20A |
30A |
40A |
|
|
Load Discharge Characteristic |
||||
|
Load voltage |
Based on battery voltage |
|||
|
Load rated current |
20A |
30A |
40A |
|
|
Load control mode |
Time control mode, PV&Time control mode, |
|||
|
On mode, Off mode, PV voltage control mode |
||||
|
Display/Communication |
||||
|
LCD display/ RS485 to USB(PC software optional), Meter, WiFi modular(APP) |
System type, PV type, PV voltage, Charge voltage, charge current, charge power, temperature etc. |
|||
|
Other Parameters |
||||
|
Protection |
Yes |
|||
|
Thermal methods |
||||
|
Products Size DxWxH(mm) |
240*168*66 |
|||
|
Packing Size DxWxH(mm) |
||||
|
Net Weight (kg) |
2.3 |
|||
|
Gross Weight (kg) |
||||
|
Type of Mechanical Protection |
IP25 |
|||
