1. Accuracy: 1%  2words

2. Range:

AC voltage: AC 80.0-300.0V

AC current: AC 0-99.99A, minimum resolution is 0.01A.Display 100.0A when the current is over 100A

Active power: 0-45000W. resolution is 0.1W (< 0-9999.9W ), otherwise Minimum resolution is 1W.

Electric energy: 0-9999999Kwh

       0-9999.999kwh minimum resolution is 0.001kwh

       10000.00-99999.99kwh minimum resolution is 0.01kwh

       100000.0-999999.9kwh minimum resolution is 0.1kwh

       The rest minimum resolution is 1Kwh.

3. Speed: 2 times per second

4. Size: 79x43x48mm

5. Installation Size:76*39mm

6. Auto-saving: when power off, the electric energy will be saved.     The saved electric energy will be accumulated continue when the meter power-on next time.
